[Fast] How to Find Bad NiMH Hybrid Battery Sticks / Cells: Use iMAX Mini to find Internal Resistance

Honda Civic Hybrid IMA battery sticks (2006 - 2011)

Here, we're using resistance to determine which sticks are ruining the pack.

EDIT: After putting sticks with low resistance into a pack and taking out high resistance sticks, the performance is much better, but not perfect so far. I still need to grid charge and discharge to cycle the battery back to as close as it can come to being good.

That's the thing. The batteries never become new or perfect ever again.

They just work better than before. :)

Cheers and best wishes!

SkyRC Mini for Internal Resistance and Battery Charging / Discharging

SkyRC iMAX B6 mini.
Honda Civic Hybrid 2006 2007 2008 2009 2010 2011
IMA Battery Module Repair
Integrated Motor Assist

finding degraded sticks / cells
P0A7F

内阻 内部抵抗 Дотоод эсэргүүцэл आंतरिक प्रतिरोध Interner Widerstand Resistencia interna Rezistenca e Brendshme المقاومة الداخلية ความต้านทานภายใน Rezistență internă İç direnç

[matthewreynolds]

This channel is exactly what i need this summer!

[panicosvasiliou]

The nimh battery resistance on a graph has a U shape. Meaning, the resistance is higher when the battery is either charged and empty, and lower when in middle range charge.
That's my two cents.

[MrKculp]

Hey I was trying the same thing you did here, though I do have the b6 mini version 2 instead, but I keep getting a reading of 0mho. was there another step I'm missing here? It does appear that I can charge and discharge, thanks for your help

[naeemwaheed]

What is the right resistence value which says its in good shape or in bad shape
