Don’t Blame the Strain Gage Sensor (10 Strain Measurement Errors)

A Micro-Measurements Foil Strain Gage Sensor with Advanced Sensors Technology is an inherently precise measurement device, easily capable of resolving one part in a million (PPM) or more.

That capability is primarily due to the exacting standards and controls under which every Micro-Measurements strain gage is manufactured. Yet many technical publication articles discuss errors. These numerous references should not be viewed as a lack of confidence in the intrinsic accuracy of the strain gage itself.

In this podcast, Darryl describes the principle errors that can arise. Often, these errors can be attributed to variables in the way the strain gage sensor is installed or the way the strain measurement is made by the user. We believe that only by thoroughly understanding the error sources associated with the use of a measurement device can the user hope to achieve optimal measurement accuracy.

So before blaming the strain gage sensor, let’s make sure these ten incredibly common strain measurement mistakes haven’t been made:
