Arduino Tutorial #7 (analogRead & Serial Monitor)

preview_player
Показать описание
Using a 10 kOhm Potentiometer, we will send a 0 - 5 V DC signal into the Arduino Analog Pin and we will make use of the analogRead instruction to print the corresponding 0-1023 value to the Serial Monitor. Then we will make some changes to the code to provide a conversion from the 0-1023 value to a 0-5 volt value displayed on the Serial Monitor that mirrors the voltage signal coming from the potentiometer.

  1. Pete Vree
  2. arduino
  3. arduino tutorial
  4. arduino uno
  5. analogRead
  6. serial monitor
