BOLT PATTERN 101: How to Measure Wheels for Perfect Fitment

Показать описание

Wheel bolt pattern can be tricky so always measure before you lay down some cash for a set of wheels at a swap meet. For 4, 6 and 8 lug wheels it’s simple. Center of one stud to the center of the one across from it. For 5 lug you measure from the outer edge of one stud to the center of the stud across from it.

In our case, we ended up with a bolt circle measurement 4.75 inches. This is commonly known as 5 on 4 and 3/4. This is a small GM pattern, used on most passenger cars from 1949 until the 1990’s. Here’s a quick guide:

5x4.75 = Small GM bolt pattern

5x4.50 = Small Ford bolt Pattern

5x4.50 = Large Mopar bolt pattern

5x4.00 = Small Mopar bolt pattern

5x5.00 = Large GM bolt pattern (Chevy trucks and ‘70s full size cars)

5x5.50 = Large Ford bolt pattern

#wheels #boltpattern #howto
