This ESP32 Antenna Array Can See WiFi

As a research assistant at the Institute of Telecommunications at the University of Stuttgart, I work on multi-antenna systems like (distributed) massive MIMO, with a focus on wireless channel measurement platforms and algorithms for processing channel measurements (classical and deep learning-based).

One day, my (incredibly talented) colleague Marc Gauger suggested to use ultra low-cost ESP32 chips instead of software defined radios for channel measurements. I was highly sceptical at first, but when he showed me a minimalistic prototype he had soldered together, I was intrigued by the idea of being able to demonstrate my algorithms in real time using WiFi signals. In a series of Bachelor's / Research theses, my excellent students Tim Schneider, David Engelbrecht and David Kellner helped me develop the ESP32 antenna array "ESPARGOS".

My research on (distributed) massive MIMO, Channel Charting and other algorithms for multi-antenna systems is funded by the German Federal Ministry of Education and Research (BMBF) within the project Open6GHub (grant no. 16KISK019).
I also want to express my gratitude towards ARENA2036, who hosted our measurement campaign for Channel Charting, and to my colleague and Channel Charting expert Phillip Stephan, with whom I co-authored several papers on Channel Charting and who assisted me with the creation of this video.
