UI Mask - Unity Official Tutorials

Watch this in context on the Unity Learn pages here -

Masks are used to hide part of a UI Image element. They can be used to define an area to animate images into, or in conjunction with the Scroll Rect component to achieve a scrollable space.

Help us caption & translate this video!

[bugzzisnu]

This is not a tutorial. Rather an overview. But it helped me to get done what I was working on, which is nice 👍

[flobzitout]

And you dont say that the element to mask have to be Child of the object that have the mask script... this is just a detail, but i was wondering why this wasn't working for me ^^

[holster]

This is awesome for minimaps: you have like the whole ui map, but the mask shows only one part of it, and it scrolls when the player moves around.

[pk]

1. This only works for UI masks, not for regular 3D sprite masks (kinda a bug)
2. Image component must be added first, Mask component must be added second (this is a bug)
3. Masked object must be child of the Mask object (intentional?)
4. Alpha value of Mask Image must higher than zero (this is a bug)
5. If your masked object has a custom shader / material - it probably wont get masked (this is a bug)
6. Why are there three different mask components and zero explanation in editor?

This is the quality of Unity built-in tools.

[bots_alive]

This video is helpful, but it lacks information on the relationship between the masking object and the objects being masked. E.g., does the masking object mask all of its descendants?

[jonathancomeau]

Thanks, I did not know it needed an Image to Work.

[Kudoshi]

Straight simple and easy. Just what i needed

[grantlo]

Great for sliding UI panel masks!! Thanks

[Cloxygen]

how can you prewrite your entire script and still eb this unclear?

[zeiksz]

Huge "like" for the "Image element" info. I don't know why that is not a RequireComponent tho'. Without that it is clearly not working.

[mrlowtherman]

Just what I was looking for, thanks!!

[threemoo]

OMG It's like listening to the bad guy in Typing of the Dead!

[Nicoyutub]

I can't get the scroll rect to work and there is no information linked below

[darrylblake]

This is great and all, but I wish you would have done the steps - step by step. As someone like myself who is new to unity, so tells me what a mask is and how it works, but doesn't show me what you did to get to that point.

[TheGreatRakatan]

Using a mask on a world space canvas causes any world geometry to also act as a mask. Using a forward rendering camera, having everything on the UI layer, nothing seems to fix this problem. Can anyone help?

[aFewBitsShort]

Can you use text as a mask instead of using an image?

[cxshoppermag]

Just tried it unity 2019.4, well it is useless followed to letter what u said for little u did parented the childs and boom total distorted image not even masking what it is supposed to do. if u ever answer let me know what's wrong Panel-image mask-mask script UI still showing with distorted corners ????

[nswell]

I am using a beta version unity5.0 20 mask but it can not run on Android phones.Showing a trace of one. Such as scratch paper is the same. Can you tell me why?

[uzar]

How can I cull UI layer for a camera I use sometimes in my game for 5 mins. I don't want to turn off the UI element.

[Throneofliesgame]

Yeah element has to be a child obj. Also, what's up with the pixelation? What's the point of shapes if it has a dominant staircase effect?
