Best Ninebot Max Dual motor set up!!! 36V up to 60V Stock D controllers. Real testing done!

Показать описание

After 13 month of using this set ups on this scooter I warrantee that work!!! Scooter was sold to a friend who is loving it as well! Find him on my FB Group!!!

It took several month of research and testing to be able to give this to you guys!!! Consider to subscribe to my channel!!!

Using scooters with stock D controllers with 60V Battery I reconfirm positively that set ups I did on this scooter work without problems!!! Hard stopping, uphill pushing 38mph this scooter takes it like nothing, stable speed with 1100W motors. No shot off, no controllers burn or anything aside of bearings I had to replace on rear wheel after 3 month of hard testing!
Ninebot Max on dual Motors with Lever electronic brake remove is the key so regen doesn't shot off the battery burning the controllers.
Yes Esnkaz put it to the test and revealed that to you guys!!!

Check out links, down the page, for big motor wiring and related information about this installation.
Ninebot Max with voltages from: 36V stock up to 60V using G30D controller and motors Stock G2 up to 1100W.
WARNING!!!! Make absolutely sure to leave the brake lever cable connection OFF connecting to the DASH of the scooter.
Leaving lever connected to dash will burn your controller!!!
Controllers will hold up 60v if not overload from regen (kers).
Remove kers completely, when making your firmware otherwise warning beeping will appear.
If you are already using mymaxmods 48v firmware is great but you will need to do a couple of changes.
1 remove completely kers. Off. (that will remove the beeping when detaching the lever from the dash)
2 increase ams from 34 to 38 or 40 continues drain.
Torque and kick or none kick you can play with as wish.

Read and understand your scooter system before making firmwares or changes to your scooter to avoid permanent damages.

Batteries tested on: 36V Stock.
36V stock plus 12V10ah from mymaxmods =48v (on full charge 54.6V)
36V Stock 15ah. plus 24V 15ah External = 60V. (on full charge 67.2V)
48V 21ah. gold edition from mymaxmods.
60V 27Ah Wolf Warrior X Pro scooter.

Another warning!!! Make sure to get information from batteries makers.
Get specifics such as battery size which are determinate by cells in series, Ams.
Get specifics of what BMS battery is loaded with that at least support drain of 50A and above.

Another tip if you are using 36V stock which is 15ah make sure that external 12V or 24V has same capacity otherwise your scooter will be shutting off at the middle of your ride.

All my testing was done using:
Ultimate batteries Molicel 21700 P42A 4200mAh 45A:
Internal 48V 25ah plus external 12V25ah total voltage 60V. smooth, torque and fast!!!

About firmware for it: 48V firmwares will work just fine!
As well speed and torque will be determinate by load, winds and terrain.
Install physical brakes on your scooter when doing this set ups.
Reinforce your scooter and ware full face helmet and full gear for your safety.
This is very important to read about all safety first before riding a fast scooter.
Need more help visit us at EsnKaz Ninebot Max Evolution USA.
By clicking link bellow will take you straight to FB group post with more details about this set up:

How to wire a big motor to use on Ninebot Max system:
