Plasticity 2024.1 | What's New | Raise Degree | xNurbs | MatCaps | MORE

We can't cover everything that has changed but here is a list of minor and major updates.
1. Minor Enhancements
. Improved the interactivity of the Radial Array command.
. Enhanced accuracy of the midpoint computation for planar face polygons.
. Export dialog now remembers the last used filename.
. Automatically name imported image OBJ files based on the original import filename.
. Introduced a new orbit rotation strategy using the classic tumble turntable approach.
. Extended the TangentCircle command to construct tangents to three curves/edges.
. Added new shaders for isophotes and draft angle analysis.
. Introduced new built-in matcaps and for advanced surfacing workflows.
. Custom matcaps
. New "ultra" faceting preference to enhance surface smoothness in surfacing workflows. Use with caution!
. Command palette now highlights clashing keybindings in red.
. Diagnostic error bodies are now displayed in the Loft and Sweep commands to identify issues like self-intersections.
. PatchCommand now optionally accepts an overbuilt sheet to trim into a hole.
. UntrimCommand has been enhanced to create holes instead of only duplicating.
. ExtendCurve command expanded to accept curves in addition to vertices, extending in two directions simultaneously.
. JoinSheetsCommand can be triggered with one sheet selected, and it will prompt to select the second sheet.
. Shift-x can now temporarily disable undesirable snaps during point picking.
. RebuildCommand expanded to replace smoothly connected edges.
. Introduced new edge snaps .closest, perpendicular, tangent
. New hover snaps for tangent circles and arcs
. New hover snaps where curves and edges intersect the construction plane ,aka "pierces", and axes.
. The measurements panel now displays angles between two edges.
. Outliner's right-click menu includes a new option to create a group with selected items.
. "Plane from selection" now allows using surface cvs to create construction planes.
. Importing OBJ STL files now prompts for unit confirmation.
. Measurements in the lower-right panel can now be clicked to be copied directly to the clipboard.
. ExtendSheet Command introduced an "up to" behavior for extending surfaces.
. Enhanced the STEP export dialog to include options for converting analytic surfaces to NURBS and selecting the STEP version.
. Added a warning for unsaved changes when opening files as well as a indicator dot for unsaved changes in general.
. Simplified the Pipe Command gizmo.
. New obj export option: "inflexion".
. Obj export can now optionally use the current matcap and disable the wireframe. This can be used to check ultra-high-resolution zebras, for example.
. Dimension Command can now resize cylinders
Major Enhancements
. Offset Face command now supports dependent offsets.
. RaiseDegree Command increases surface complexity by converting analytic surfaces to spline and increasing the spline degree.
. Surface CV editing now allows direct manipulation of both trimmed and untrimmed faces.
. Faces with visible cvs now have a "nominal" surface to allow easier edits in the presence of direct editing
. RemoveNominalSurface Command is available in case it needs to be removed
. Introduced TogglePoints command to show hide points on faces, curves, and bodies.
. Added scaling options to the Pipe and Sweep commands.
. Implemented a "Full Round" fillet option.
. "Rebuild" command now can rebuild the surfaces of faces; extend and shrink options allow for easily overbuilding surfaces
Small but Significant Changes
. Dragging CVs of curves and surfaces now aligns with screen space; previously it was parallel to the construction plane
. Enhanced sketch operations to confirm with a single Enter press or single left-click.
Studio-Exclusive Features
. Integrated the xNURBS addon for high-quality surface construction.
. Added support for Rhino 8 imports.
Noteworthy Optimizations
. Enhanced parallelism in OBJ/STL exports.
. Object transformations now bypass refaceting on confirmation for efficiency.
. Implemented 16-bit snorm normals and 16-bit indices where possible to optimize memory usage.
