2007 - 2012 Mazda CX 7 Radio install | AVH-1400NEX

Parts used linked in the description below!

Watch a full tutorial as a Mazda CX-7 will have a new Pioneer Double Din radio installed. We will be using the Pioneer AVH-1400NEX touch screen bluetooth radio. This radio features Apple Carplay while retaining the factory BOSE sound system.

Click here to see the backup camera install video:

Great tutorial on how to install a backup camera:

This video applies to Mazda CX-7 models for years 2007, 2008, 2009, 2010, 2011, and 2012. Note: 2010-2012 features a slightly different dash bezel, but the install will be just the same. This video also includes complete radio wiring, complete installation, and testing.

If you have any questions, leave a comment below! Be sure to like and subscribe!

Parts Used (Amazon Associate / eBay Partner Paid Links):
*Pioneer AVH-1400NEX Double Din Radio (Discontinued)

*Disclosure: As an Amazon Associate / eBay Partner I earn from qualifying purchases*

[ProvoBeastAudio]

Parts used linked in the description of the video!

[spaceisyourmind]

For anyone that DOES NOT have the BOSE system: If you hooked everything up, and the radio turns on and functions, but the audio sounds "flat, static-ey" and has "no bass" AND the EQ settings dont work on your new radio. What you wanna do is cut off the RCA audio connectors, separate the two wires for each; Front Left, Rear Left, Front Right and Rear Right, and then just wire the speaker wires one by one like installations without the RCA connectors. The audio should be louder, crisper, and the EQ settings should work. If you dont know if you have BOSE or not, just open the trunk and lift the plastic cover that hides your spare wheel. If you dont have a silver looking box screwed underneath the Driver side back seat, then you dont have BOSE system. Should have wires connected to it and all. That was also my problem because i THOUGHT i had BOSE, because the Factory radio had "BOSE" settings only available to vehicles with it, but my CX-7 didnt have a BOSE fuse, nor BOSE Amplifier in trunk area. So just be sure to find out if you have BOSE or not. hope this helps anyone with same issue.

[tim]

Thanks for sharing. Do you still have full functionality of the digital information screen in the dash? i.e. clock set, mile until empty, etc

[showreadycarsllc]

That's a great install 👌 and excellent work with a seamless finish 👏 👍.

[nickkarp]

Idk if you’re still active but i have a question. The original stereo has the smaller harnesses attached to it. I see you put the big harness (white) into the new harness (orange). What did you do with the other smaller harnesses (white)

[rubenramirez]

What if I have the stock in dash option with back up camera does it work.the same this unit.

[billygreen]

Great video
I have a cx7 also was asking the average cost to replace in aud

[Yosoyflaco]

Hello thank you for the video
I have a Mazda CX-7 2009 I install and android radio but my voice recognition is not working, I have install the canbus for the Mazda that came with the unit.
Any ideas thank you

[camilomiranda]

I would be Happy to see the bypass connect on harness to ?

[dannyk]

Great vide I have an 07 with Bose premium with nav will the same components work and operate the clock (which is currently showing the wrong time?) along with the factory blietooth

[johnmay]

As far as the steering wheel controls. Does the phone control options still work with new radio?

[paulgrabowski]

I have a 2009 CX7 with the navigation, Bose and Bluetooth and reverse camera. Couple I use this unit and retain all these features?

[TJsVette]

I guess they changed the radio style from 2011 to 2012 cause my radio is completely different.

I also already have a back up camera from the factory can that be used or will I have to get something different?

[panagiotiskrokos]

Just curious, where can we get controls with voice button and call accept/close??? I dont have these in my 08 cx7

[brandonnewton]

how do you retain the factory mic? Is this possible?

[johnmay]

I recently change out my factory radio with steering control wiring as well. The volume up/down works but the answer/end calls buttons no longer are functional. Is that normal?

[diegodelabarra]

hello change the radio for an android, with original harness ... turn on and the control at the wheel works. but the bose audio does not turn on with which cable do you turn on the amplifier? help

[kendrathompson]

If my cx 7 mazda doesn't have the answer call on the steering wheel will the pioneer avh 14000 still work for my car?

[gabbyrodriguezclavijo]

I installed Pioneer AVH-X8850BT stereo radio in 2007 Mazda CX 7 with RP4-MZ11 interface but it doesn't work, could you tell me what the cause is and help me to solve it, thank you very much.

[mckinneymichael]

Can you add this system to a 2010 CX7?
