Quick Line Array Tuning Level & EQ in Smaart®

Here is what I have been doing when I only have time to measure a single array in Smaart:
1. Place 3 mics: VTOP, ONAX, and VBOT.
2. Observe all three transfer functions, plus a live average.
3. Make level and EQ decisions compared to a target trace.
4. Listen to reference track with EQ in/out.

___
___
___
___
Be friendly
___

I love to geek out about the physics of sound. This channel focuses on the growing opportunity for live sound engineers to improve their confidence and consistency through the understanding of the principles of sound system design and optimization. My goal is to make this channel upfront and honest about my success and failure, so you can learn from both.

I am always open to suggestions and feedback so please comment on this video or contact me through my site.
_______________
Smaart® and the Smaart logo are registered trademarks of Rational Acoustics LLC and are not affiliated with Nathan Lively or Sound Design Live.

[WDesertForce]

Bob's book suggests that it's a bad idea to run array sections at different levels because you lose LF directional control. Instead, he suggests HF equalization (per array section) to level match. You can see that some speaker manufacturers include this concept into their array-able enclosures with HF shelf buttons.

[MatbiangShadap]

Hi nathan, do you have a video that details how to set limiter values for the amp and speaker from a DSP processor. How do we calculate the voltage of the amplifier if only the sensitivity is known, and how to use this information to derive the proper values to set in dBFS and dBu.

[bertrandbillon]

Hi Nathan, for multi-mic measurements, I understand the difference of contribution to average between matched or equal gains, but I can't make a choice. what are good and bad sides of each ? thanks. Bertrand

[symphonystudioaz]

Hi Nathan..Can you please do a video on how to connect and configure like 2 mics into the hardware and I/O routing inside smaart? The looping of outputs is confusing to me. Thanks.

[robinslive]

Hi sir.. great videos.... it’s really helpful to me.. I would like to know what’s the minimum height we require for flying a line array speakers!!! May be its a stupid question..but I am learning.. thanks ;)

[sal]

How many elements does each of the subsystems VTop, OnAx and VBot consist of, in this case?

[kdigitalproductionservices]

Hie Nathan

And what about the coherence in the magnitude window? Does it matter if you're not getting good coherence above 70% for your EQ decisions to be accurate?

[manuotero]

Is it worth having a tablet connected to the PC of the system to control it remotely and to be able to change the positioning of the microphones or is only a 4-channel interface more than enough? It is quite frustrating in large venues to continually move for mic positioning between FOH and mic position.

[ZCorradoVRZ]

Nathan, I'm looking for an interface to take measurements in REW or Open Sound Meter, I'm just a hobbyist and can't really spend much on this project.
With that said, is the Steinberg UR12 a good interface to use for this? Where I live it costs nearly half the price of the Focusrite Scarlett Solo 3.

[flocktheband]

Question- for that dip you can see in smaart around 2k.. you wouldn’t bring that level up at all to try and fix the dip?

[matthewsears]

Where do you get your target traces in Smaart from?

[TheTylrBllmn]

These zones are per array correct? Then you're running the mix in mono?
