An intuitive approach for understanding electricity

In this video, I try to explain electricity Ohm's Law… using a LOT of different demonstrations and analogies. I've been working on this script for like a year and a half now - this took SO long to assemble because electricity is an absolute pain to learn and to explain. I crammed every analogy to describe electricity I could think of into this video (which is why it's... oof... 40 minutes... who's going to watch this?).

When I learn something hard, it's normally after I've seen it a few times before, so with a tough topic in this video, I'm trying to scatter-shot and hope that at least one demo clicks for everybody! If it DOESN'T click for you, let me know what's weird! There will be an FAQ about this video posted on the second channel in a few weeks. If you want to ask a question, drop it in the comments here, or if you want to make sure I see it, leave a note on the new Patreon Discord server!

The biggest intentional omission in this video is not addressing radial charge distribution in a wire, and I know that's going to annoy some of the commenters here. I only talk about 1D wires so I don't have to confuse people by making them imagine different families of electrons at different parts of the wire when at the end of the day they can all get squished and move the same way - so please consider all of my diagrams with electrons getting "more concentrated" to be looking all the way through a wire, including the surfaces :)

Thanks to the VERY FIRST Channel Superfans from Patreon!
birdiesnbritts
John Sosa Trustham
Vladimir Shklovsky

Chapters:
00:00 Intro to Ohm's Law
04:18 Current
06:18 Resistance
08:30 Voltage
19:43 The water Channel Model
25:06 Power and Energy
31:32 Clarifications

Media Credits:
Heavenly Choir, Monty Python and the Holy Grail
Move Ya by Max Surla/Media Right Productions is licensed under YouTube Music
Mountain by Text Me Records is licensed under YouTube Music
Vespers by Topher Mohr and Alex Elena is licensed under YouTube Music
Switched on Carcassi by Brian Bolger is licensed under YouTube Music
Way Out West by Chris Haugen is licensed under YouTube Music

[AlphaPhoenixChannel]

FAQs and corrections in this comment!
I'll answer some of the most common comment questions here, but in a few weeks, I'm going to post an actual post-video FAQ video on the second channel including questions from the comments here, and questions from supporters on Patreon!

1) Pre-emptive answer: The distance any given electron needs to move to "pool up" behind a resistor is miniscule, but you can't ignore it. It's tempting to say that the moment you connect a wire, electricity is a pure wave where the electrons don't move from their starting positions, but in reality they just BARELY move from their starting positions. Imagine a big long line of people, and all the people in the back of the line take one step forward - now the front of the line is crammed SLIGHTLY closer together on average - that's kinda what's going on. The scale of all of this is really weird, so demonstrations amplify it, then the demonstrations get questioned for amplifying it too much…

2) lots of people asking about inductance. In the case of the water trough model, the inertia of the flowing water is similar to inductance, and if you wanted to make the inductance larger, you could put a waterwheel with a large moment of inertia in the channel. It would be hard to spin up, and then it would be hard to spin down once you got it going.

3) lots of commenters have correctly pointed out that my “replace all the electrons” statement was too general. I am referring to all mobile electrons, which in a metal refers to one valence electron per atom. However all of these electrons, no matter where they live in the wire (in the middle or on the surface) chug along at the same drift velocity and eventually would be “replaced” if you had a way to mark them
