SPI oled is faster than I2C oled!? (SSD1306 speed test Arduino)
Показать описание
This video is not made for kids.
In this video i compare the speeds of an SSD1306 oled display module of SPI and I2C.
Although an esp32 is faster than an arduino, the I2C data requires manual pin control to send uneven and strange bits to the controller (stray bits, 6-bit, and 8-bit all at once.) SPI however takes straight 8-bit inputs, which doesn't require manual pin control (except for the reset, dc, and cs inputs) and is much faster.
I have plans to remake this video. Stay tuned.
In this video i compare the speeds of an SSD1306 oled display module of SPI and I2C.
Although an esp32 is faster than an arduino, the I2C data requires manual pin control to send uneven and strange bits to the controller (stray bits, 6-bit, and 8-bit all at once.) SPI however takes straight 8-bit inputs, which doesn't require manual pin control (except for the reset, dc, and cs inputs) and is much faster.
I have plans to remake this video. Stay tuned.
