Restoration & Repair of Xbox 360 with Red Ring of Death

Restoring and repairing Xbox 360 with red ring of death and stuck disc drive. I got this Xbox as part of broken console lot from Ebay with some Playstations.

I started by checking the error code the console gives. Mine is 1023, which is almost always related to a cold solder in CPU or GPU. The disc drive is also not working. I can hear it trying to open but I doesn't.

To repair the red ring of death I used a heat gun. My heat gun is part of a soldering station but you can use a normal one also. Mine was set up to 400 degrees Celsius. The idea is to heat up the CPU and GPU until the solders underneath melt. The chips can be damaged by heat also so it's important to move the heat gun around. The board is pretty much ruined and not if you can't fix it, so you are not losing anything if you try this and fail. After the initial warm up I added flux which will help the reflow of the solder joints. During heating adding the flux you don't want to touch anything on the board because the solder should start melting and your parts can come off of the board and it can be very hard or impossible to put them back. After heating the CPU and GPU for a while I let the beard cool down before I touch it. Now the board is hopefully working. if not you can try again if you want.

I could hear that the disc drive was trying to open so I figured it was probably just filled with dust. I tested it and the motor which spins the disc didn't move up and down as it should. This prevented the drive from opening. I removed the covers from the drive and cleaned it. After cleaning the disc drive was working well.

Thank you for watching my video!
