Programming FPGA Board using QSPI Protocol | Basys 3 Board

preview_player
Показать описание
Learn how to program the FPGA board using QSPI protocol in few easy steps.

The Basys3 board contains a 32Mbit non-volatile serial Flash device, which is attached to the Artix 7 FPGA using a dedicated quad-mode (x4) SPI bus. FPGA configuration files can be written to the Quad SPI Flash (Spansion part number S25FL032), and mode settings are available to cause the FPGA to automatically read a configuration from this device at power on. An Artix-7 35T configuration file requires just over two Mbytes of memory, leaving approximately 48% of the flash device available for user data. The connections and pin assignments between the FPGA and the serial flash device can be seen at the link below:

===================================================================
