Learn SolidWorks in 1 minute | How to duplicate a sketch using linear pattern
Показать описание
#solidworks #3dmodeling #duplication
In this example, holes will be added to the cuboid by drawing one sketch and duplicating it. This will be done by using the linear sketch pattern option and extruded cut feature.
- SolidWorks 2020 version was used and this teaching video can be used in any version.
- Video editing: iMovie
In this example, holes will be added to the cuboid by drawing one sketch and duplicating it. This will be done by using the linear sketch pattern option and extruded cut feature.
- SolidWorks 2020 version was used and this teaching video can be used in any version.
- Video editing: iMovie
