Sorting ASP NET Chart Control using Sort method

Text version of the video

Healthy diet is very important both for the body and mind. If you like Aarvi Kitchen recipes, please support by sharing, subscribing and liking our YouTube channel. Hope you can help.

Slides

All ASP .NET Chart Control Text Articles and Slides

ASP.NET Charts Playlist

All Dot Net and SQL Server Tutorials in English

All Dot Net and SQL Server Tutorials in Arabic

In this video we will discuss sorting ASP.NET chart control using Sort() method. This is continuation to Part 9. Please watch Part 9 before proceeding.

To use Sort() method

[table style="font-family: Arial; border: 1px solid black"]
[tr]
[td]
Sort By :
[asp:DropDownList ID="ddlSortBy" AutoPostBack="true" runat="server"
OnSelectedIndexChanged="ddlSortBy_SelectedIndexChanged"]
[asp:ListItem Text="Student Name" Value="AxisLabel"][/asp:ListItem]
[asp:ListItem Text="Total Marks" Value="Y"][/asp:ListItem]
[/asp:DropDownList]
[/td]
[td]
Sort Direction :
[asp:DropDownList ID="ddlSortDirection" AutoPostBack="true" runat="server"
OnSelectedIndexChanged="ddlSortDirection_SelectedIndexChanged"]
[asp:ListItem Text="Ascending" Value="ASC"][/asp:ListItem]
[asp:ListItem Text="Descending" Value="DESC"][/asp:ListItem]
[/asp:DropDownList]
[/td]
[/tr]
[tr]
[td colspan="2"]
[asp:Chart ID="Chart1" runat="server"]
[Series]
[asp:Series Name="Series1"]
[/asp:Series]
[/Series]
[ChartAreas]
[asp:ChartArea Name="ChartArea1"]
[/asp:ChartArea]
[/ChartAreas]
[/asp:Chart]
[/td]
[/tr]
[/table]

Step 2 : Modify the code in the code-behind file as shown below.
using System;
using System.Data;

namespace ChartsDemo
{
public partial class WebForm1 : System.Web.UI.Page
{
protected void Page_Load(object sender, EventArgs e)
{
if (!IsPostBack)
{
GetChartData();
}
}

private void GetChartData()
{
DataSet ds = new DataSet();
Chart1.Series["Series1"].XValueMember = "StudentName";
Chart1.Series["Series1"].YValueMembers = "TotalMarks";
Chart1.DataSource = ds;
Chart1.DataBind();

// Sorting
if (ddlSortDirection.SelectedValue == "ASC")
{
Chart1.Series["Series1"].Sort(System.Web.UI.DataVisualization.Charting.PointSortOrder.Ascending, ddlSortBy.SelectedValue);
// OR
// Chart1.DataManipulator.Sort(System.Web.UI.DataVisualization.Charting.PointSortOrder.Ascending, ddlSortBy.SelectedValue, "Series1");
}
else
{
Chart1.Series["Series1"].Sort(System.Web.UI.DataVisualization.Charting.PointSortOrder.Descending, ddlSortBy.SelectedValue);
// OR
// Chart1.DataManipulator.Sort(System.Web.UI.DataVisualization.Charting.PointSortOrder.Descending, ddlSortBy.SelectedValue, "Series1");
}
}

protected void ddlSortBy_SelectedIndexChanged(object sender, EventArgs e)
{
GetChartData();
}

protected void ddlSortDirection_SelectedIndexChanged(object sender, EventArgs e)
{
GetChartData();
}
}
}

References :
