BLDC Speed Control Using Pulse Width Modulation (PWM)| Brushless Motor Control with Simulink, Part 3

This video discusses pulse width modulation (PWM) and two different architectures to implement PWM control for controlling the speed of a brushless DC (BLDC) motor. PWM is a square wave signal that repeats itself at a certain frequency. With PWM, we’re able to adjust a constant DC voltage to different voltage levels to control a motor at varying speeds. The video demonstrates two common architectures for PWM control. In the first one, we use a buck converter along with a PWM generator to step down the DC source voltage to the three-phase inverter. In the second one, we discuss a different architecture where the three-phase voltages are modulated directly using PWM control.

The model used in this video is available in this GitHub repository:
Design-motor-controllers-with-Simscape-Electrical/1 Simulating back emf voltage of a BLDC motor at master · mathworks/Design-motor-controllers-with-Simscape-Electrical · GitHub

Additional resources: -

--------------------------------------------------------------------------------------------------------
