Using an EEPROM to replace combinational logic

You can get all the components used in this video from any online electronic components distributor for a few dollars.

Complete parts list (everything in this video):
- 1x 28C16 EEPROM
- 8x LEDs
- 8x 330Ω resistors
- 1x 8-position DIP switch
- 1x 4-position DIP switch
- 12x 10kΩ resistors
- 1x 100nF capacitor
- 1x 680Ω resistor
- 1x momentary tact switch
- 1x Common Anode 7-segment display
- 1x 100Ω resistor
