Arduino HC-05: Bluetooth Smart Home Lighting Simulation w/UNO, LEDs, mBlock 5 + Android [Tutorial]

preview_player
Показать описание
0:00 Introduction
0:39 Fritzing Diagram
0:54 Components Required (aside from Android smartphone)
1:50 PART 1: Building the Arduino Smart Home Lighting Device
10:03 PART 2: Configuring HC-05 module w/HC-05 Bluetooth Configurator
13:02 PART 3: Installing app on Android smartphone & HC-05 module pairing
17:13 PART 4: Coding w/mBlock 5 + 'HC-05 Bluetooth PCM' Extension
29:14 PART 5: Configuring & testing Android smartphone app w/Device
32:53 End

ESSENTIAL LINKS
===============

#arduino #hc05 #smarthome #mblock #mblock5 #homeautomation #homelighting #led
Рекомендации по теме
Комментарии
Автор

This isome of the slickest videos I've seen all day working on amd learning this stuff. Bravo....thank you for taking the time amd sharing.

wadebrewer
Автор

I thought the HC-05 TX and RX pins were 3.3V pins, but you have them connected to 5V pins on the UNO. For the UNO pin that receives data from the HC-05 I guess this isn't an issue, but the output pin on the UNO will be 5V when turned on, so wouldn't this be a little too much for the HC-05? Won't it eventually, if not immediatley, smoke the RX circuit on the HC-05?

codecage
Автор

Cool video, but why mBlock? It's such a weird way to write code.

Tiparium_NMF
Автор

Hi, could you use the Arduino Uno instead of the Arduino R3? I don't have the Arduino R3, I will appreciate your response.😁

danielamolina
Автор

if none of them are working try 9600 baudrate

Rznovfps
