Mikrotik Basic Configuration Plus Dual Wan PCC Load Balancing.

Tutorial by: Kelvin Magday

Creation of Bridge:

1. Go to Bridge
2. Click the "+" button
3. Name it as "LAN"
4. Enter

Addition of port to Bridge

1. Go to Bridge
2. Go to PORT tab
3. Click the "+" button
4. Select the interface you want to add to the bridge
5. Enter

WAN Configuration: We have different types of WAN configuration. Via PPPoE Client and DHCP Client. In this case, we are using PPPoE Client as our WAN:

For ISP1:
1. Go to PPP
2. Click the "+" button
3. Click PPPoE Client
4. Go to DIAL UP tab
5. Enter the username and password of you pppoe given by your ISP
6. Select Ether1 as the interface
7. Enter

For ISP2:
1. Go to PPP
2. Click the "+" button
3. Click PPPoE Client
4. Go to DIAL UP tab
5. Enter the username and password of you pppoe given by your ISP
6. Select Ether2 as the interface
7. Enter

NAT Configuration for WAN:

1. Go to IP
2. Go to NAT tab
3. Click the "+" button
4. Out. Interface is pppoe-out 1
5. Enter
6. Click the "+" button again
7. Out. Interface is pppoe-out 2
8. Enter

DNS Configuration

1. Go to DNS
2. Set servers as 8.8.8.8
3. Click allow remote request

LAN Configuration:

1. Go to IP➤Addressess
2. Click the "+" button
3. Address: 192.168.88.1 /24
4. Select Interface: LAN
5. Enter

DHCP Server Configuration

1. Go to IP➤DHCP Server
2. CLick DHCP Setup
3. DHCP Server Interface is you "LAN" bridge
4. Then next until it's done.

Address List:

1. Go to IP➤Firewall
2. Go to Address List tab
3. Click the "+" button
4. Name is "LAN"
5. Address: 192.168.88.0/24
6. Enter

Mangle (Connection Mark Configuration)

1. Go to IP➤Firewall
2. Go to Mangle Tab
3. Click the "+" button
4. Go to Advance Tab
5. SRC Address List : Drop Down and Select the "LAN"
6. Per connection classifier
both addresses and ports 2/0
7. Go to Extra Tab
8. Dst Address Type:
local
check Invert
9. Go to Action Tab
Action:mark connection
New Routing Mark:wan-1con
10. Enter
11. Click the "+" button again
12. Go to Advance Tab
13. Per connection classifier
both addresses and ports 2/1
14. Go to Extra Tab
15. Dst Address Type:
local
check Invert
16. Go to Action Tab
Action:mark connection
New Routing Mark:wan-2con
17. Enter

Mangle (Routing Mark Configuration)
1. Go to IP➤Firewall
2. Go to Mangle Tab
3. Click the "+" button
4. On the General Tab select the connection mark as: wan1-con
5. Go to Advance Tab
6. SRC Address List : Drop Down and Select the "LAN"
7. Go to Action Tab
Action:mark routing
New Routing Mark:to_wan1
8. Enter
9. Click the "+" button again
10. On the General Tab select the connection mark as: wan2-con
11. Go to Advance Tab
12. SRC Address List : Drop Down and Select the "LAN"
13. Go to Action Tab
Action:mark routing
New Routing Mark:to_wan2
14. Enter

Routing Configuration:

1. Go to IP➤Routes
2. Click the "+" button
3. Enter the gateway of your PPPoE Client (ISP1)
4. Select the routing mark "to_wan1"
5. Enter
6. Click the "+" button again
7. Enter the gateway of your PPPoE Client (ISP2)
8. Select the routing mark "to_wan2"
