General Motors 8L90 mechanical operation and powerflow

This video is part two of a seven part series on the GM 8L90 transmission. In this video, I cover the mechanical operation and powerflow. I describe the transmission identification, gearset components, clutch assemblies and I describe powerflow in each gear.

Here are the other videos in this series:

8L90 Rebuilding Particulars:
8L90 Modifications and Tuning:

Special thanks to Precision International, TransGo, and Sonnax for providing me with product to use in these videos. Also thanks to KB Cores and AA Midwest for providing me with a few 8L90 cores at a good price!
