Index PnP Assembles Circuit Boards!

So awesome to have the Index actually do some useful work, populating ring lights for a batch of machines I'm assembling! I had confidence it would be able to do this based on previous validation tests, but to actually have it do the thing it's designed to do, full stack, feels incredible.

-------------------------------------------------------------------
