Noctua SecuFirm2™ AMD AM5/AM4 offset mounting installation

Noctua's SecuFirm2™ mounting systems are renowned to be among the most convenient on the market. This video shows how to install Noctua multi-socket CPU coolers on AMD's AM5/AM4 platforms, using the AMD offset mounting bars (NM-AMB12, NM-AMB13, NM-AMB14, NM-AMB15).

Further information:

[iainballas]

The part that helped me was seeing the thermal paste application. It's what I'm most worried about botching, other than doing the BIOS flashback to update for the X3D processors in the AM5 slot. If I can do those bits, then I can build my own computer. I chose this fan because I didn't want to mess with liquid cooling, and people are saying they keep their Noctua fans for years. So it's just a few dots, then press down? Neato.

[lowskinator]

I just bought the nh u12a, which offset mounting bars would i need for that air cooler? Much appreciated all you do for your customers noctua, trully one of the best companies who actually cares about their customers and delivers quality products

[holloweatmysoul]

My NH-D15 already getting an average 44c now I can get a approximate-3 best 5 dollars

[adamchua]

need remove the themal paste guard or not??before install the cooler

[IbrzuVow]

Hi, I'm looking to build myself a new PC and I was planning on getting the NH-D15 for my CPU, which will be the Ryzen 7 7800x3d. The problem from what I see is that NH-D15's RAM clearance is only 32mm, while the RAM sticks I want to use are 34.9mm tall.

How hard is it to move the outside fan? Is it just a matter of putting it up slightly higher and that's it? No need to worry? For further info, I'll be using a Fractal Torrent case, which has 188mm as maximum height for the cooler.

[mascapt]

Interesting, is it include in new NHd-15 product ? or maybe i need to buy the the NM-AMB12 product separately ? i have planned to buy the NHD-15 for my new ryzen 7 7700X.(AM5)

[Madherk]

Do you tighten till the screw stops? Or is that too much

[nymphetemine]

I'm assuming you keep that little plastic thermal guard on?

[gianluca]

I recently bought this Nh-d15 heatsink, when I disassembled it to change the CPU I noticed that the contact plate was off-centered towards the bottom and that the upper part of the CPU was outside the plate, this position is named -7mm on my instructions, AM5 7 9800x3d CPU, are the instructions reversed? The offset position is perfectly centered on the CPU, I don't understand how it is possible even if the main dies are on the southern part of the CPU because it is better that the plate does not adhere to the heatsink but rather leave it outside the plate. Please help me.

[Bugsplatt_gbg]

Is it a -7mm offset from center of the holes or is it -7mm between the hole radiuses? :)

[chigalipup]

Hello! Ryzen 7 7700. I couldn't find any tests online with or without a 7mm offset. Which position would be better? Is there a big difference?

[jrksoldierx]

Does this offset bracket fit the Msi X670E Carbon and the d15s? I know the d15s fits on the carbon without the offset.

[Ytgul]

Does the offset really make a difference? Anyone have any comparative values for me? Thing is, with offset setup the tower comes a bit too close to the graphics card backplate, that´s why I´m using standard setup instead. Package temps in Prime95 at max temp test arround 83° Grad.

[Shinjitu]

What is the plastic piece you put right before applying the thermal paste? Do you need to remove it afterwards or is the heatsink mounted with that plastic?

[scottylans]

I have ordered
NM-AMB12 for my very very old
NH-C12P (SE14)
I don't have an AM5 mounting kit :( but I do have an old
NM-AM4 kit
With those 3 components, will I be ok to mount this properly with 7mm offset on ITX B650 Mothetboards? (AsRock)


Oh and thank you guys, so much for being so diligent and consumer friendly, I've already ordered more Noctua fans for my next system.

[YesMyMaster]

Maybe will help someone... The compatibility list for this bars is currently incomplete.
In my case, NM-AMB13 bars fit NH-P1 radiator. So far, this information is not available anywhere.

[tibot]

Please tell me if I have these mounts NM-AMB8 . Will they fit the socket am5 or is it better to buy NM-AM5/4-MP83 mounting-kit required. Processor 7800x3d motherboard 670/ Thx

[powiedzMyy]

There was torque, :D I've bought 0, 4 to 2Nm torque screwdriver for pc building :)

[federicocapriotti]

Hello, i bought nd-h15 in 2022, i bought an am5, do i have to buy the adapter separately or i can install it on the mount i already have

[sporadicentertainment]

Does the new Noctua nh-d15 g2 have a new am4 offset brackets?
