DJI O4 Lite: not-quite-perfect air unit for micro drones

---

I receive a commission (at no extra cost to you) if you make a purchase after clicking one of the affiliate links below.

Buy the 04 Air Unit (Mini/Lite) at:

Buy the 04 Air Unit Pro at:

Buy the 04 air unit, G3 goggles, and other related gear at:

---

00:00:00 - Replacing HDzero with DJI? Heresy!
00:02:41 - 04 is not truly 1S-rated. Min voltage 3.7 volts.
00:04:04 - 25mm mounting, DJI Compatible plug
00:04:55 - Voltage regulator installed in the O3 plug
00:05:43 - O4 Lite pulls about 9 watts
00:06:09 - Drop-in replacement for HDZero or O3
00:06:56 - O4 Lite has lower TX power than Pro

00:08:13 - Lite supports 60 Mbs and Racing, but latency is higher than Pro

00:09:12 - Missing framerates and resolutions
00:10:26 - Lite doesn't have D-Log color
00:10:49 - Lite has longer internal recording, but no SD slot
00:11:19 - Flight Test: 700 mW, 60 Mbps, 4k60
00:14:01 - Lite has worse range/penetration than Pro or O3
00:14:25 - Flite Test: Racing Mode at 700 mW
00:16:28 - Flight Test: Racing mode at 25 mW
00:19:02 - Detailed comparison of Lite, Pro, and O3 cameras
00:23:39 - The Lite is not exactly a disappointment ...
00:24:44 - Who is the O4 Lite perfect for? And who's it NOT for?
00:26:14 - The Lite is only disappointing in comparison to the Pro

[UAVfutures]

Can we just appreciate bardwells style here. That jacket is fire.

[bEEBO]

Just starting out with FPV and can't believe how good Joshua's channel is. Learnt so much on here!

[blackjungle]

How do you expect us to focus on FPV, DJI and specs, when you're wearing such an amazing jacket? Looking snazzy, my dude.

[conorstewart]

What I would use the o4 lite for would be mainly focussed on just having fun, not trying to get good footage. Just something to put on a tinywhoop to get better image quality and potentially range than I am getting with analogue. The range and penetration on analogue just isn't great, it is mostly good enough for a tiny whoop but I would like better. If I was interested in filming then I would go for the o4 Pro.

[Timsmith]

I tried using your link to purchase the new 04, hope you get the commission. Thanks for your videos. You are a blessing to the community

[GurwinderSingh-ufn]

I will never get bored of your video's

[thebra]

O4 lite is perfect for me as I've only ever done analog and fly tinywhoops. Ordered the Pavo Femto and Meteort65. So excited to try it. My wife is ready for me to stop talking about, lol.

[Jaa__]

O4 lite is for newbies just starting to me. Just right for me. Next drone is going to be a pro. But when your budget is low. And you just want to build something. I think it’s pretty ok.

[FilipRadelic]

21:55 and 22:37 you mixed up the sensor sizes - O4 Pro is 1/1.3" and O4 Lite is 1/2", not the other way around.

19:27 there's definitely wide fov option on the lite (you said normal was its biggest fov) and it's very close to wide on O3 and O4 Pro, only very slightly narrower.

20:04 there's no Gyroflow support at ultra wide on O4 Pro (or O3), you need to shoot in wide to have gyro data available (that's the case on all DJI stuff that supports Gyroflow).

Anyway, one important thing I would note is that since Goggles 2 and later fov in live view isn't affected by your recording fov setting, using the lite might actually be preferable for some people because it's less fisheye-y. I think some racers in particular might like that. I'll personally be using Pro on everything except my 1S 65mm whoop (22g isn't that bad, just a couple years ago Meteor65 and Mobula6 analog were around that weight or a bit more and we loved them).

[superdstar]

Perfectly content with Moonlight and 1s v3 lite kit. The 04 is exciting but I don't feel like I'm missing out.

[wrightwells]

The range of that ‘lite” unit compared to the Walksnail lite!!! That was impressive. Every review is about image but honestly when you don’t trust the range and the way it breaks.

[rgilroy]

thanks JB. I'm sticking with my 03. WAS excited for the 04 lite, but I'll keep waiting. What a heart burn. Feels like it was rushed.

[CiottiFPV]

AMAZING review, super excited to put one on a 2s 75 :)

[jumpstartfpv]

O4 lite is what I think everyone else will also call it. Just makes sense. Everyone except DJI

[handledrandomly]

Are you planning on doing a test on o4 lite with an aftermarket antenna?

[eliokreier]

Thanks for the interesting findings. Can you test the o4 lite with the circular antenna and see if the range and penetration is better?

[MaxMorfiX]

18:58 Bardwell has summer on one shot and already winter on the next one. Btw I liked your previous pfp more

[olacfpv]

Definitely the best review of the O4 system. Thanks Mister Bardwell !

[Alec]

The footage from the new FX3 looks nice!

[epikepok]

thank you so much for the warning about the voltage... i think that without you, my brand new o4 lite would have burned..
