Modifying a Dixon quick change parting blade holder

I'm modifying a useless parting blade holder for my new Dixon QCTP in to a holder for a small boring bar. It was a bit of a struggle, with a view hiccups, but overall I''m very happy with the result. And I'm sure this modified tool will be a very useful addition to my lathe turning tools arsenal.
