How its work - Compressed Air Driven - Air Amplifier

These are simple vacuum pumps based on a venturi airflow design that can be used for vacuum pressures up to 28" of mercury vacuum. The pumps require a source of compressed air in order to function but require no electricity. Once the source is hooked up the pumps can be set up to reach vacuum pressures from atmospheric pressure to 28" and all pressures in between can be regulated.

Principle of Operation
When compressed air is forced through a conical nozzle, its velocity increases.  This principle was discovered by a 18th century physicist, G. B. Venturi and can be applied to generate vacuum economically without a single moving part.

[nipongvaj]

Nice! Good Work, this definitely amplifies the tube better! :)

[gman]

How much psi can one add to a air line using one

[nipongvaj]

Question! Is air being affected on the Outside of the tube as well? And how is the amplification maximized at optimal performance far as tube "A" goes? As in do you need to make tube "A" bigger or smaller to increase power of amplification?

[indvacuumcorporation]

We are under designed process ! welcome for suggestion!

[indvacuumcorporation]

yes we need a compressed air to drive first and then flow continue by using atmosphere air

[kalbropumps]

simple vacuum pumps based on a venturi airflow design

[indvacuumcorporation]

Air Amplifiers are designed to boost existing air
