Install OpenWRT on Mikrotik routers - Mikrotik HAP AC2

In this video, we will install OpenWRT on Mikrotik Routers. I used the Mikrotik Hap AC2 as an example. The tutorial can be applied on other models, such as the Mikrotik hEX (RB750Gr3), RB3011 and RB4011 since all Mikrotik routerboards share the same common procedures.
** Installing a third party firmware on a Mikrotik router could void your warranty, lost your license key and even brick the router. Therefore, please watch the video carefully and proceed as your own risk **
The video is long, but there are only 3 main steps:
1 - Backup your RouterOS license key
2 - Netboot the OpenWRT initramfs (Initial Ram Disk) with Mikrotik.
3 - Write the OpenWRT image to NAND permanently

Video timeframe:
00:00 - OpenWRT on Mikrotik Routerboards - Common Procedures
01:40 - Backup RouterOS license key
02:44 - Download OpenWRT images/firmware for Mikrotik routerboards
03:09 - OpenWRT firmware for HAP AC2
04:00 - Download Tiny PXE Server and configure the Network Adapter for Netboot
06:49 - Netboot OpenWRT initramfs (Initial Ram Disk) on Mikrotik HAP AC2
08:40 - How to know if OpenWRT is running on the router
09:42 - Access LuCI on Mikrotik HAP AC2 and tests (LAN, WAN, WiFi)
15:38 - Permanently flash the OpenWRT image to NAND of Mikrotik
18:40 - How to configure VLAN for WAN port?

Resources:

Good luck!

[Kamis]

After many hours i finally made it to my Mikrotik RB750 thanks to your tutorial. The hardest part was i used 19.07 soft and i dont work. Then i used 18.06 for initrams and then upgrade to 19.07

[zadekeys]

Nice video! Thank you! I'm in progress of setting up a DIY WiFi Pineapple on a RB951G2HnD. Hoping to also add external antenna's aswell. Using a USB 5v to 12v converter, allows me to power the unit via it's DC jack, using a laptop or power bank. :)

[marcusrav]

I want to try this on my rb4011 but openwrt website doesn't show its compatible. In the description of the video it says it does. Where do I get the firmware?

[eld]

Thank you for the tutorial..the official guide on openWrt is correct but very confusing and general. You were straight forward :)

[pyaethukyaw]

I can't find firmware please give me a link bro

[carlsson]

Thank you for your video! It helped me a lot to install OpenWRT on my hAP ac² from the Linux machine. But there were some difficulties. RouterOS ver.7 and later 6.xx versions DO NOT ALLOW to boot other operating systems via TFTP. So, I finally managed to do it by downgrading to an earlier (factory) firmware version 🌞

[nerdstark]

I couldn't do it without this tutorial. Thank you.

[YutuPremi-knyb]

Tengo una hap ac2 pero tus archivos no están e flasheado otras versiones snapshot pero ninguna me trae la opción services y la de vpn

[ricardorosado]

When I try to change the cable from port 1 to port 2 it doesn´t finish flashing openwrt. I never see the message RELEASE received. Any solution?

[صدامالقزع-هص]

Can I upload a NanoStation M2 software
to Mikrotik router board 2011?

[PejuangGSM]

have u ever try with hap ac3 bro? it will be nice

[GeorgeOrwell-]

how i can find job in vetinam?) network engineer 11+years expirience

[edysusilo]

for install OPENWRT must be connect UART(serial port HAPac2) to PC or only Lan (port 1) to PC ?

[virtualworld-]

Is there anyway to dual boot RouterOS and OpenWRT?

[halfeez]

Is it the same procedure for RB2011UiAS-2HnD? I have one sitting in the corner, thinking to flash it with OpenWrt

[gaudoitech]

He bro it's possible to get openwrt openvpn&passwall on mikrotik 750gr3?

[AI-EXREYFOX]

Why you install 2 Times the openwrt, have que do that for all other brands

[GeorgeOrwell-]

does it have usb support?
wanted to use as a print server

[YutuPremi-knyb]

En iame tus archivos necesito la opción services y vpn

[ocg]

Hi, thanks for the video! I have a doubt Can I install OpenWrt with RouterOS 7.6? factory version is 7.3.1 so in theory it's not possible to downgrade to 6.x.x right?
