BA-60W BATTERY COB WASH 60W

BA-60W BATTERY COB WASH 60W

Light Source
Lamp: 1*60W 4 in 1(RGBW)LED lamp
Life span: 50,000 hours
Color: RGBW

Optics
Beam angle:26º
Improved optics and flat beam field

Power Supply
Input Voltage:AC90-260V 50/60Hz
Power Consumption: state of charge180W, non-charging sate: 80W.

Battery
Battery type:Lithium iron
Battery charge time:0% to 100% charge 5.5 hours,
Max-endurance:8 hours(Full power), 12 hours(built-in program)
Temperature detection function :(-20 ℃ to 45 ℃)
Battery protection:Battery short circuit protection, over current protection,overflow charging
Charging mode:When connected to mains and power is insufficient, battery will be charged automatically.
Support battery extension.

Control
Control Signal:DMX512, master-slave and sound activated or auto operation
Control Channel:12/10 DMX channels USITT DMX-512
DMX recorder and function integrate

Movement
16 bit smooth and precise resolution for PAN/TILT movement
630° /540° /360° PAN and 270°/180° /90° TILT movement optional
PAN/TILT reversible advantage
PAN/TILT calibration available
Scan position memory,auto preposition after unexpected movement.

Working Environment
-35-45°C max ambient temperature
Constant temperature readout and management function.
Protection Rating : IP 20

Construction & Weight
Dimensions:38.59(D)*30.6(W)*22.4(H)CM
Packing Dimensions:28(D)*37(W)*42.5(H)(CM).
Net Weight:9.48 kgs
Gross Weight: 11.5 kgs

Features
ABS die-cast plastic cover with Aluminium structure
High performance LED strobe
Strobe effect with 28 flashes per second and pulse effect
0-100% Linear LED dimmer
Scan function reset, all function reset.
Preset variable/random strobe and dimming pulse effect
Switching power supply output with short protection function
POWERCON connector IN
3-Pin XLR connectors IN/OUT
2.4'' TFT LCD display (320*240pix)
A*safety fuse:4A overtime,blow fuse
