Click PLC Counter Programming Example

We will now look at a programming example of a click plc counter. Programming counters in the click plc will be demonstrated through a ladder logic example.
More information can be obtained on our website. This includes all of the links mentioned in this video.

Previously we discussed:
Click PLC System-Hardware.
Click PLC Installing the Software
Click PLC Establish Communication
Click PLC Numbering System and Addressing

Continuing our series, we will now look at timers and how they are used in the Click PLC.

Check out the Click PLC Timers

00:00 Click PLC Counter Programming Example
00:32 Adding a Counter using the programming software
04:41 Downloading PLC program to Click
05:16 Monitoring the Click PLC Counter
07:10 Click Counter Non-Memory Retentive

Download the Click Programming software at the following address:

There are several reasons why we are using the Click PLC. Here are just a few.
- Investment is low for the hardware and the software is free
- Standalone PLC with built-in I/O
- Communication ability - Ethernet Port, RS232, RS485 - support for protocols such as Modbus RTU, Modbus TCP, etc.
- Ability to expand the system with a variety of modules including RTD and Thermocouple inputs directly.
