CODESYS: Using TON and CTU function blocks in Structured text (ST) programming

-------------------------------------------------------------------------------------------------------------------------------------
In this video, you will learn how to use the Timer and Counter function blocks in ST programming. TON is the on-delay timer and CTU is the up-counting counter

[metanigga]

Hi there! I have a strange question: can I use timer with variable time (not fixed - 1s, for example with "t" seconds, where I can write any value on "t")?

[ikramantaki]

is it possible to connect CODESYS with any PLC for example, Im using WECON PLC EDITOR

[Flofet]

Hello,
is there any way to stop the turn on delay?
For example using a stop button means stop counting the time-> motor won't turn on

[preetparmar]

Hi there i am new to codesys i am trying to run an output say a motor for a set time but i cannot find the right funtion block/timer for this can you help me out

[ronniegems]

Hi, can you make a video on "Encoder programing and simulation with Codesys Structure Text? " I searched a lot, but couldn't find it. It will be much helpful...

[fcbfcbfcb]

Hi Tohid, I am trying to implement a delay of for example 5seconds. What I tried is make a TON and then an if loop so it looks like this:
my_ton : TON;
my_ton(IN:= TRUE, PT := T#5s)
label1: counter1 := counter1+1;
IF NOT(my_ton.Q) THEN (*As long as Q is low, go back untill Q is high (so after 5
JMP label1; seconds) *)
END_IF
But for some reason it doesn't recognise the label. Do you know how to solve this. I also tried doing this with a while loop but that makes my PLC crash.
Thanks in advance!
Bart

[jeevarathinam]

Post a video using jump command program and also traffic signal program
