NLS | Single Channel Digital timer 16amp 24Hr / 7 Day Battery Backup

NLS | Single Channel Digital timer 16amp 24Hr / 7 Day Battery Backup
Available at Sparky Direct - Electrical Online Wholesaler

These compact single channel digital timer units fit on a din rail and can be used to control, pool pumps, lights, garden fittings, and many other applications. Easy to set .

Technical Data

Type: Electronic with LCD display
Rated voltage: 230V AC
Rated frequency: 50/60Hz
Contact: 1NO+1NC
Consumption: Maximum 4VA
Contact capacity:
16A/250V AC (COSφ =1)
2.5A/250V AC (COSφ =0.6)
Incandescent lamp: 1000W
Electrical endurance: 105cycles
M Time basis: Quartz
24 hours+ week program
Working precision: ≤ 2 sec/day (25° C)
Min. Programmable interval: 1minute
Power reserve: Min. 15 days
Ambient temperature: -10~40° C
Humidity: 35-85% RH
Connection terminal: Pillar terminal with clamp
Connection capacity: Rigid conductor 6mm2
Installation
on symmetrical DIN rail
Panel mountingechanical endurance: 107cycles
Construction and Feature

Compact modular size
LCD Display
Equipped with back-up battery
Permanent switch ON/OFF
Application
The product is applicable to circuit with rated current 16A, rated voltage 250V and rated frequency 50/60Hz. It provides independent electrical control to switch on-off the circuit at programmed times and days of the week.

Please check the type of load that will be placed on the timer ie 'inductive or resistive' and use an appropriate contactor if required.
Inductive = Running a for of motor or high in rush current
Resistive = Basic lighting or heating
