BTA41-600BRG electronic component

Rated Average On-State Current:40A
Brand:Jsmsemi
Package / Case:TO-3P
Mounting Type:Through Hole
Package Type:TOP3
Maximum Gate Trigger Current:100mA
Repetitive Peak Reverse Voltage:600V
Surge Current Rating:420A
Pin Count:3
Maximum Gate Trigger Voltage:1.3V
Repetitive Peak Forward Blocking Voltage:600V
Maximum Holding Current:80mA
Dimensions:15.5 x 4.6 x 12.85mm
Length:15.5mm
Width:4.6mm
Height:12.85mm
Repetitive Peak Off-State Current:0.005mA
Peak On-State Voltage:1.55V
Maximum Operating Temperature:+125 °C
Minimum Operating Temperature:-40 °C
