Mounting Animation of the E-Line KD Data Rack Busbar! Please refer to

Our new DATA RACK BUSBAR addresses to scalability issues for reliable and flexible Moves- Adds-Changes in your data center white space power infrastructures.
E-Line KD Data Rack Busbar can supply power from 160A to 800A current rating.
To power the mission critical IT infrastructures on the Data Rack Cabinets, EAE offers a highly flexible and reliable Busbar System to meet the "Scalability" challenge in the Data Centers finding the way to Moves, Adds and Changes (MACs). The Data Rack Busbar also serves for powering and metering of non-standard Cabinet Rows in data centre white space environments. Tap-Off boxes are easily able to plug-in on any point alongside the busbar, remove and relocate wherever necessary with vendor neutral components for energy monitoring. The choice of AI or Cu up to 6 conductors enables design and budget flexibility while the mono block joint mechanism provides peace of mind for secure and long-life operations.

Technical Features:
1- Customized Energy Monitoring Tap-Off Boxes with Plug-Play alongside the busbar
2- Fast Installation by Snap-In Suspension Mechanism
3- Mono Block Joint Mechanism
4- IP23D for enhanced IP Protection Level
5- Safe Locking Mechanism for Tap-Off Boxes equipped with specially designed long-life contacts ensuring constant contact pressure on the conductors
6- Easy Positioning of the Tap-Off Boxes on the selected Rack Cabinet alongside the Rack Cabinet rows by means of a special holder mechanism which also provides that the weight of the box is supported by the busbar housing

This video provides step-by-step instructions to install KD Data Rack Busbar systems.

00:10 Data Rack Busbar Overview
00:23 Installation of hangers
00:26 Installing the Busway
01:03 Installing Tap-off Box
