SB2 Passive Summing Mixer Kit – DIYRE - DIY Recording Equipment
Показать описание
Audio Builders Workshop will be unboxing kits and DIY audio parts, and tools from Collective Cases, DIY.RE, Microphone-Part, JLM Audio, Hairball, Expat Audio, Bumblebee DIY Pro Audio, Austin Microphones, Audibility Recording, GKL gKit Baby / ORA, Vintage Microphone PCB Kit, Sparkos Lab, Geistnote and many more!
The SB2 is a standalone 8/16x2 passive summing mixer in a ultra-compact format. Using minimal, completely passive circuitry, it sums 8 or 16 balanced line inputs down to a single set of stereo mic-level outputs.
FEATURES:
Ultra-low cost and small footprint
Accepts 8 or 16 balanced inputs
DB-25 (D-SUB) input connectors
Balanced, microphone-level outputs
XLR output jacks
Neoprene foam pad for desktop use
The SB2 is a standalone 8/16x2 passive summing mixer in a ultra-compact format. Using minimal, completely passive circuitry, it sums 8 or 16 balanced line inputs down to a single set of stereo mic-level outputs.
FEATURES:
Ultra-low cost and small footprint
Accepts 8 or 16 balanced inputs
DB-25 (D-SUB) input connectors
Balanced, microphone-level outputs
XLR output jacks
Neoprene foam pad for desktop use
