BMW E60 M5 / M6 S85 Throttle Actuator & Idle Actuator DIY

This E39Source DIY demonstrates how to replace the throttle actuators and idle actuators motors on the 2006-2010 BMW E60 M5, E63/E64 M6 S85 V10.

PARTS:

(2) Throttle Actuator: 13627834494
(2) Idle Actuator: 13417834495
(2) Idle Actuator Gasket: 13417836405
(1) Idle Actuator Hose: 13417837711
(1) Idle Actuator Hose: 13417837712
(2) Idle Actuator Hose Clamp: 64218367179
(6) Idle Actuator Nut: 07129905471
(10) If Needed: Plenum Bottom Hose: 11617834685
(10) If Needed: Plenum Bottom Hose Clamp: 11617835320

TORQUES:

Throttle Actuator to Engine Block: 89in/lb
Idle Actuator to Engine Block: 89in/lb
17mm Starter and Jump Nuts: 18.4lb/ft
Wiring Harness to Engine: 89in/lb
Ionic Module Cover to Cylinder Head: 89in/lb
