2017 Hyundai Sonata starter replacement

replacing the starter on a 2017 Hyundai sonata 2.4

[diegobuen]

Hey I just did it this way. Thank you so much, learned a lot about my car being thorough like this. Just want to add one thing, it’s not just 5 bolts/nuts of the intake manifold to remove. If it still doesn’t budge, check underneath the manifold- there is a BRACKET there with 3 bolts.

[giogonza]

U can do it without removing intake manifold, just did one today, remove neg bat cable, remove air box assembly, remove bracket with 4 - 12mm bolts holding it under the intake maniifold, remove the 12mm nut holding the cable to the starter solenoid, unplug the connector to the starter and lastly remove the 2 14mm bolts holding the starter and its out

[readthebones]

Thanks man, appreciate you putting up this video - not much online about doing this type of job on newer Sonatas

[samcorona]

Thanks for the video, good job explaining and showing!

[rickydlp]

Is there a way to access the starter without removing everything? I just want to hit it a couple times to take it to car shop. I replaced my other starters but they usually just got pulled out by the bottom of car no other work needed

[alexg]

Why did you take all that apart when you could have just UN-bolted it then reach your hand behind the manifold pull it out UN-plug and UN-bolt it and been done????

[JessyLame]

Did the cart begin starting after new starter was replaced ?
