ctrlX DRIVE – DC/DC converter XMV2 with resistance loads

The modular drive system ctrlX DRIVE includes the DC/DC converter XMV2 in various current ranges. This enables applications where DC power is supplied or absorbed at user set DC voltage and current setup.

This video provides:
- Brief explanation of the DC/DC converter function.
- Simple examples with
- Resistance load operated at 20 to 275VDC
- AC power ctrlX DRIVE supply XVR2 supplied with
3x240 VAC and regulated DC bus of 400…750 VDC

• Video content:
00:08 Introduction
00:25 Application types for DC/DC converter: Energy buffers such as battery, super capacitors,
battery simulation and other DC energy sources, common DC bus, interface to AC grid
00:42 DC/DC converter XMV2 technical data snapshot
00:58 DC/DC converter XMV2 - Example demo setup with resistance load
01:09 ctrlX DRIVE regulated power supply XVR2
01:14 Isolation transformer with grounded TN Grid
01:24 Regulated drive system DC bus
01:30 DC/DC converter system 80 ampere
01:34 XMV2-W0080… DC/DC inverter feeding into the smoothing choke XLL
01:40 DC smoothing capacitor XLC
01:45 High voltage transducer for closed loop voltage control
01:50 Auxiliary components such as DC fuses, contactors, additional sensors
01:59 System controller ctrlX CORE with suitable Apps
02:06 EtherCAT bus with safety controller ctrlX SAFETY and S20 IO
02:13 Web based HMI with WebIQ for use with stationary and mobile devices
02:25 Demonstrator setup
02:34 Component review
03:36 DC/DC converter XMV2 - Example demo setup 1, resistance load halogen light
03:46 Operating the system (HMI close up)
03:49 Supply voltage 240 VAC
04:00 Drive system DC bus voltage regulated by the XVR power supply
04:00 DC bus voltage is adjustable between 400 to 750VDC
04:11 Output data of a DC/DC converter with 80A at 400 VDC bus
04:19 halogen lights operating limits
04:30 Operating the halogen lights with the DC/DC converter
04:45 Activate the power supply XVR2 with 400 V DCbus
04:51 DC/DC converter operating screen overview
05:15 DC voltage control setup, 20 to 250 VDC
05:37 DC contactors ON with halogen light
06:06 DC current control setup, 0 to 80 A
06:20 Halogen light operation
06:48 DC/DC converter XMV2 - Example demo setup 2, resistance load 3.4 ohm
06.51 Resistor load (3.4 ohm, 500 kWs) equals 80 A at about 275 VDC
07:31 Operating the resistor with the DC/DC converter
07:36 XVR2 supply regulates the DC bus at 600 VDC
07:45 DC output voltage of 220 VDC results in 65A and 13.3kW power
08:10 DC output current command of 23.8A results in 1.9kW power and 80 VDC
08:32 DC output current command of 90A results in 21.7kW power and 275 VDC
08:53 Output power easily adjusted with voltage control
09:04 DC/DC converter XMV2 - Example demo setup 3, resistance load 2 x 3.4 ohm parallel
09:25 Enabling the DC/DC converter
09:46 Operating the load in current control at 80A
09:58 Operating the load in voltage control at 80A
10:22 Discharging of the DC smoothing capacitor using a discharge resistor
10:52 Summary
