Vanquish Products F10 Portal Axle Step-by-Step Instructions

The Vanquish Products F10 Portal Axles come equipped in the new VS4-10 Phoenix. These are the first molded axle design from Vanquish Products. These axle feature an ultra rigid portal housing design that will handle serious abuse.

Start of Front Axle - 0:14
Third Member Assembly - 0:21
Brass Front Tubes - 2:33
Front Stub Axle - 2:55
Front Portal Cover - 3:18
Steering Knuckles (inner) - 3:53
Front Axle Shafts & Upper Portal Gear - 4:40
Knuckle onto Axle Housing - 5:12
Shims/Washers - 5:44
Start of Rear Axle - 6:08
Third Member into Rear Housing - 6:18
Rear Brass Tubes - 6:39
Rear Stube Axle - 6:53
Rear Portal Cover - 7:13
Rear Axle Shafts - 7:43
Rear Portal Cover Install - 8:13
Rear Oil Fill Cap - 8:27
Shims/Washers - 8:57

Follow My Social Media!

My Camera/Production Gear:

[toddbertram]

It blows me away the variable overdrive has just hit the market now. Better late than never. The Phoenix seems like an amazing kit. Just another great product from the leaders in the scale rc world.

[cncrcOG]

started building mine this morning, been fun so far, but visual videos help me thanks for the upload! Will be watching the others as well thanks again

[Art-zssl]

Brass inserts? Cool! These look very nice. I like the Phoenix body as well.

[openoutlaw]

Excellent instructional video. My wife is going to be building her rig soon and this video should make it very easy for her. Thank you

[billderas]

Excellent video. Went back into my rear axle assembly to check that I had properly oriented the two axles. And, I had...LOL

[allmightygreatone]

Thank you for the informative videos. When it's time to repair my traxxas trx4 I will certainly need to view your traxxas how to videos.

[ferdis]

When will the axles be available separately? :)

[flatlander]

Just picked up my kit this weekend. Going to try a R3008SB receiver with my 7PX. Hoping the castle telemetry works with the extra channels.

Keep up the great content. Much appreciated!

[nathanstewart]

I'm sure I'll be going back and watching all of these videos. I have one on back order from Amain. I'm ready to get started on it.

[saturnfivehynrgrc]

Josh

Many thanks for putting in the time/effort. Product development, support and marketing is an exhausting effort that never stops. This truck is certainly on my watch list. Job well done and I hope Vanquish recognizes your efforts. Side note: Check the Three Stooges "Dizzy Doctors" a good laugh (my opinion) on the goo gone/goof off thing. Cheers

[johngookinsable]

Cool video! Always helpful info from Harley Design

[timhutchinson]

The shims would go on the inside of the pinion gear to adjust the ring and pinion

[lacucaracha]

From the transmission this might be my next kit, finally a gear shifter that dioesnt seem to have 50° of wheel rotation before it engages

[splatteredfrog]

Hello Josh I have a question about the f10 rear portal axle shaft can't find the replacement part using the parts list vps08611. Or is there a different shaft that fits ?

[GeezerGramps]

I’m I to assume that all the bearing are lubed at the factory?

[dragonflyjoyride]

Thanks for the build of the axles. Can the ring gear be put on the right side or left side of the pinion or is it only 1 direction? I have no kit.. yet. Will the axles ever be sold separately? If someone wanted to buy them. Thanks

[mikebrewz]

This is my first kit so I don't know what I'm doing 😂. A friend told me to fill the diff and portals with grease to keep water out. Is this ok?

[kraafishjp]

Whould the Portal box's work on older 10.2 vanguish portal's

[Sackboy]

Are the bevel gear can switch to other side?

[danielkonrad]

On my kit, the brass tubes do not fit snug, they are totally loose and fall out easily. Should'nt they fit tight? On the front axle they are nice an tight in the housing.
