AGP【DM10 / DM14 Rig Mounted Diamond Core Drill】Product Operation

Показать описание

★ AGP【DM10 Diamond Core Drill Motors】
High efficiency 3500 W motors with an Aluminum body for maximum performance. Three models are available with a range of gearings for different needs.

★ Product Information
Power Input｜
■ 3500 W /16 A (220 V)
■ 2800 W / 25 A (110 V)
Voltage｜
■ 220 - 240 V ~ 50 - 60 Hz
■ 110 - 120 V ~ 50 - 60 Hz
No Load Speeds min-1｜ 450 / 810 / 1300
Rated Load Speeds min-1｜ 270 / 480 / 780
Drilling Capacity｜ Ø300 mm (12")
Gear Oil Type｜ 90 W
Gear Oil Capacity｜ 625 ml
Spindle Thread｜
■ 1-1/4” UNC male
■ 1/2” BSP female
Protection Class｜ Class I With PRCD / GFCI
Soft Start & Overload Protection｜ With
Dimensions (L x W x H)｜ 550 mm x 155 mm x 210 mm
Weight｜ 12.9 kg (28.4 lb)

★ Learn more about the【DM10 Diamond Core Drill Motors】

★ Connect with us

★ For further information please visit our websites

--------------------------------------------------------------------------------------------------------------------------------------------------------------

★ AGP【DM14 Rig-Mounted Diamond Core Drill Motor】
A high efficiency 4 speed, 3500 W motor with an Aluminum body, optimized for a wider range of drill sizes in one tool.

★ Product Information
Power Input｜
■ 3500 W /16 A (220 V)
■ 2800 W / 25 A (110 V)
Voltage｜
■ 220 - 240 V ~ 50 - 60 Hz
■ 110 - 120 V ~ 50 - 60 Hz
No Load Speeds min-1｜ 385 / 530 / 975 / 1340
Rated Load Speeds min-1｜ 225 / 300 / 565 / 780
Drilling Capacity｜ Ø400 mm (16")
Gear Oil Type｜ 90 W
Gear Oil Capacity｜ 625 ml
Spindle Thread｜
■ 1-1/4” UNC male
■ 1/2” BSP female
Protection Class｜ Class I With PRCD / GFCI (110 - 120 V W/O PRCD/GFCI)
Soft Start & Overload Protection｜ With
Dimensions (L x W x H)｜ 550 mm x 155 mm x 210 mm
Weight｜ 13.5 kg (29.7 lb)

★ Learn more about the【DM14 Rig-Mounted Diamond Core Drill Motor】
