IR Series - BGA Rework Systems || Full 'Features & Benefits' Video
Показать описание
In this video, we go through all of the benefits and features of our new line of InfraRed BGA Rework Systems.
Order of Events:
0:00 - Title Sequence
1:26 - Top and Bottom IR Heaters
1:40 - Non-Contact IR Pyrometer
2:21 - Integrated Software
2:45 - Time and Temp Parameter Adjustment
3:03 - Setting Target Trigger Temperature
3:33 - Saving A Heating Profile
3:43 - Flux Application
4:00 - Vision Overlay System
4:24 - Quad-Field Imaging
4:38 - Auto/Manual Removal and Placement
5:00 - Pik-Vac Tool
5:08 - High Sensitivity Vacuum Pick
5:24 - Heat Shields
5:32 - 6 Standard Vacuum Picks
5:40 - Optional Vacuum Picks
6:11 - Hi Definition Sodr-Cam
6:40 - Max PCB Size
7:03 - V and L Grooved Board Holder
7:15 - Integrated Board Support
The IR3100 and 4100 InfraRed Rework Systems can easily install and remove BGAs, QFNs, μBGA/CSPs, Flip Chips and other SMD's. Featuring a 500W infrared (IR) top heater and 1000W (1900W for IR4100) IR bottom preheater. The IR Systems do not require nozzles. A specially-developed IR pyrometer provides non-contact, real-time, closed-loop temperature control throughout the reflow process. A Sodr-Cam Reflow Camera comes standard, allowing you to watch the entire reflow process in real time. The IR Systems' newly designed Windows-based software makes profiling incredibly simple for even the most advanced applications, providing intuitive set-up, multi-stage profiling, on-the-fly profile adjustment, flux-dipping, unlimited profile storage and much more.
