Build a Meccano Dog Clutch Mechanism [VirtualMEC Build #1]

I wanted to build some simple Meccano mechanisms to gain a better understanding of both the building system itself and basic engineering principles. This model was chosen for it's simplicity and ability to function as a module in a "do-nothing machine". As with any model involving moving parts, it needs adjusting and fine-tuning to get it working just right. I believe this may have been featured in a Meccano Magazine in years past.

Video one of three in a series of VirtualMEC builds.

Original Builder: Ricky Mekano
Build Time: 15-30 min
Total Number of Parts: 45
Different Parts: 17
Estimated Weight: 0.153 kg

Software used for this Video:

Lots of plans and ideas for future models. Stay tuned!
