Parker OS12B and Encoder with Copley StepNet - Open Loop

preview_player
Показать описание
In Open Loop Micro stepping mode, I was able to obtain the suggested 50rps or 3krpm by increasing the current loop bandwidth, selecting max-speed option, using parallel winding, and increasing the DC bus greater than 24V dc.
