Introduction to Current Transformers Part 2: CT Polarity

🚀𝐀𝐋𝐋 𝐈𝐍 𝐎𝐍𝐄: 𝐏𝐨𝐰𝐞𝐫 𝐒𝐲𝐬𝐭𝐞𝐦 𝐁𝐮𝐧𝐝𝐥𝐞!🚀

In this series, we will introduce the current transformer and will give an example where we would want to use a CT. We'll also look at polarity marks for CTs and talk about the current transformer ratio and how to relate primary current to secondary current. Then we will take three CTs and connect them to the WYE and delta connection. In the last, we will draw the current transformer model and show the voltage currents and impedance's that are associated with the CT model.
