Daewoo Puma 12L-B CNC Lathe

EMC Leasing Company

We are liquidating this 12" Chuck Daewoo Puma 12L-B lathe.

Please let us know if you have any questions.

Best regards,

Rick
Rick Adams
EMC Leasing Company
Tel: [phone]

DAEWOO PUMA 12L-B CNC LATHE
NEW 1995

Swing 22.4"
max swing over Turret Slide 15"
Max Turn Dia 19"
max Turn Length 40.2"
Spindle Speeds 20 - 2,500 RPM
Spindle Nose ASA A2-8
Spindle Motor 35 HP Motor
Chuck Size 12"
Thru Hole 3 1/16"
X Travel 10.2"
Z Travel 41.3"

X / Z Rapids Traverse 480 / 630 IPM
Turret Config 1 Turret / 10 Stations.

Tailstock Quill Stroke / Diameter 4" / 4.3"
Programmable Body Stroke 41.3"
Taper of Center MT #5


Equipped With:

Mitsubishi CNC Control
Tailstock
12" 3-Jaw Chuck
Turbo Chip Conveyor
Coolant System
Misc. Tooling

[joecobra]

its not over riding the interlock, by the way" is what its properly called" you must be a noob to cncs, when you enter service mode, usauly a m250 code, will allow the whole program to run, no matter if the doors open or not, only difference is, it will run at way less rmps, like the newer model pumas, 700 rpm will be aorund 300 some max out at 350

[OscarRamirez-qxky]

Hello, how touch the x axis with the tools .please help me

[floydy]

You must be over riding the door lock?
