Microcontroller 8051 Project 01 How to Interface a LED with microcontroller

In this series, you will learn the Microcontroller programming In C Language and in Assembly Language.

LED
A light-emitting diode is an electronic component that is available in different shapes, sizes, and current ratings.
These are widely used in electronic circuits.
LED emits light when the electric current flows through it.


LED can be connected to a microcontroller output port in two different modes:
• Current Sinking
and
• Current Sourcing

Current Sinking Mode

In the current sinking mode, the cathode leg is connected to the microcontroller output port, and the anode leg of the LED is connected to the positive 5 Voltage power supply through a current-limiting resistor. The LED is turned ON when the output of the microcontroller is at logic 0, so the current flows through the LED.


Current Sourcing Mode
In current sourcing mode, the anode leg of the LED is connected to the microcontroller output port, and the cathode leg is connected to the ground through a current-limiting resistor. In this mode the LED is turned ON when the microcontroller output port is at logic 1.



Current Sinking Mode
How To Find the Value of a Resistor

If the voltage drop across a LED is 2 Volts.
And the LED current is 10 milliamperes.
Source voltage is 5 Volts.
And assuming the microcontroller output voltage is about 0.4 volts when the output is low,
So, we can calculate the value of the required resistor.
