Toyota CVT TC Auto Transmission Oil Change

We have physical workshop(Kepong) for installation, kindly Google Map/Waze search Zhapalang Motorsport

If you have a Toyota vehicle equipped with a CVT, you are encouraged to get the vehicle's transmission unit inspected after 50,000 KM.

#Toyota #CVT #OilChange

[rickybissessar]

The procedure to remove the oil is standard, Filling the oil is the technical part. When you replace the plastic straw at the bottom pan, you start filling the oil. Using approximately the same amount of oil as what you took out. A guy here mentioned Oil temperature. he is ABSOLUTELY CORRECT. you must get a scanner. Start the engine. Let it idle until the TRANSMISSION oil temp is between 109 to 114 degrees F. you can use a computer scanner on the car itself or a basic laser temperature scanner on the transmission bottom oil pan. Its not about engine temperature. when that temperature is achieved, you continue filling oil until oil flows out of the straw. this would indicate the correct oil level. you then replace the drain plug and tightened. Transmission oil expands with heat. that's why you need that specific temperature range. Hope this helps. Trust me. I did the research guys.

[人車-ht]

the most clear explain I found in youtube for Toyota CVT fluid replace.

[gerrybracamontes]

I changed the CVT fluid on my 2014 Corolla S with 140, 000 miles. Mostly freeway miles. I commute 200 miles daily. The fluid that came out was so black and it stunk. Basically I just followed the visual instructions on this video. Of course, I couldn't read the subtitles but its pretty self explanatory and the video was very helpful. I kept the car leveled, I think that's important. I noticed that about 2 inches above the fill plug is another fill plug black in color. I found this plug difficult to access and put a funnel or hose in it. So I used the fill plug they use on video. It was much easier. Began by removing fill plug. Then remove plug from pan and let drain. Then remove that little tube from inside the pan. The video shows a longer tube than mine, looks like metal. Mine was half that size and orange plastic. Once it stopped draining, I measured the amount of used fluid using a empty jug. I then poured the same amount of fresh fluid into a separate jug. Insert the plastic tube in pan and I started to fill trans thru fill hole. Once fluid started coming out the bottom, I had my wife go thru the gears while I continued filling as fluid poured out the bottom. I had to use a little more fluid than I had previously measured. I did this till fluid came out clear red. At this time we stopped going thru the gears and put it in park. I waited till it stopped dripping and then I installed drain plug. Installed fill plug and put car back together. Overall it was fairly easy. I did it in my garage, lifted rear of car on ramps and jacked up the front to level it. Greaf video and very helpful. Thank you.

[robertsghostv]

Correct CVT oil change for Toyota CVTs ! Good mechanic !

[esakhan]

For the first time I seen this thing is so easy ...all other videos were hell difficult

[blueadept]

Thank You! Been looking all over on how to change sealed transmissions for yaris/vitz and you've come through with a solution, Thank You Sir! :-)

[vineviewfarm]

really liked your video, just wish there was some English!

[rffster]

Your step
-open oil sump nut and drain
-open secondary nut inside it and drain
-close secondary nut
-fill new cvt oil untill some of oil come out from drain
-start engine, press brake, alternate gear R-N-D change untill some oil come out from oil pan and back to N, at the same time fill the oil.
-close back oil fill nut
-close back oil drain nut

[TheJoeMB]

This is much better info than what i found on forum called Pakwheels where it says say you remove the entire sump (which has 13 bolts) and you have to replace the sump gasket (which is difficult to find as it isn't a commonly replace part).


Explains why, the second drain tube is removable which is something the author on the post of Pakwheels did not seem to be aware of.



I just wish the subtitles of this video were in English, would it be possible to update the captions in the video description? it would really help.

[uabbasi]

Hi it is very professional . Can you tell me where is refilling cap or bolt in Toyota auris 2018 hybrid UK

[ssenkasicharles]

When do you change the cvt transmission oil and when do you change the filter.Especially in off road and dirty conditions or dusty

[levisngutuku]

I started experiencing erratic gear shifts from parking to Drive on my allion 2011 but when its come to changing gears, my car is okay. I changed cvt and the car was okay. after sometimes it started again, the mechanic told me 4 tires fluid could not be enough since we drained everything, I topped up 2 litres and the car was okay. after some few km, the problem has started again. Is the transmission fluid not enough or what is the issue

[vincenttantan]

Thanks for the good video and very clear and informative, i alway met different mechanics with different way for changing CVT. Recent change is they just fill up the 3 litres, they said too much oil will cause problem. i insisted to do N.D, and then top up till 4 litres finish. months later, the drive shaft right oil seal leaked. Seal no damage. So now they only let me top up 3 litres + only. please advise whether it is enough? will it affects my gear box. alot of AXIo got gear box damage problem . Worse is this car no Dipdick to check. Any advise ? Or correct me if i am wrong.

[noyaanbatoor]

What is the precautions before changing the oil? Some says the car need to be parked overnight to let the engine and gear oil get cool and then in case of toyota axio fielder 2007.

[alanthonybien]

Hi. What are the tools you used to change the cvt transmission oil in this video?

[luismaldonado]

Gracias. Me ayudó mucho. No sabía que el tubo se podía desenroscar. Y sacarlo para drenar todo el aceite.

[AftabAli-qpqr]

I almost destroyed my Toyota Camry transmission by changing the fluid again and again flushed it 5 times transmission was jerky I didn’t know what to do tried every YouTube method.then I come across one video almost same as this guy does.I put the transmission in reverse and about 109f on the pan let the excess fluid drained and it finally worked now I feel a slight jerk into second gear the rest all fine.

[dannimake]

Did you changed the gaskets and oil filter?😳

[zsoltnyari]

do you know where can I find the refill for automatic transmission a toyota avensis t27?I see the drain but cannot find where to refill it. would like to change the transmission fluid. Any help would be much appreciated. thanks

[armandolios]

Hi, you say INSPECTED after 50k km, how about REPLACED?. Great video by the way.
