Leadwell T-7 CNC Lathe 2001 Fanuc O-TO Control

Leadwell T-7 CNC Lathe 2001 Fanuc O-TO Control
Model: T-7
SN: L2TJJ043JF
Year: 2001
Chip Conveyor
Bar Feed Interface
13.78” x 21.25” CNC Turning Center With Fanuc 0-TO Control
20 HP, 12 Position Turret, 8” 3 Jaw Chuck W/ 2” Capacity, Chip Conveyor
General Specifications:
Max. Swing: 20.4”
Max. Turning Dia.: 13.7”
Bar Capacity: 2.5”
Chuck Size: 8”
X Axis: 7.6”
Z Axis: 23.6”
Max. Spindle Speed: 4500 RPM
Spindle Nose: A2-6
Number Of Tool Positions: 12
X Rapid Traverse: 780 IPM
Z Rapid Traverse: 936 IPM
Spindle Motor: 20 HP
Approx. Machine Weight: 10,000 Lbs.
Bar Feed Interface
2” Capacity Chip Conveyor
Stock 12850
