Performing receiver SINAD and S+N/N measurements.

In this video I give a tutorial on how to measure basic receiver sensitivity using the SINAD and S+N/N measurement procedures.

[VintageElectronicsGeek]

Awesome Craig, will have to try this when I have a chance and see how I prosper....thanks for doing! ~Jack, VEG

[LeeWhiting-kx]

In your first test of the Icom on FM @144Mhz, you used .56uV, which is used until 50MHZ. @ 144mhz, it should have been .2uV

[canalcomentario]

In the case of traditional CB radios based on the EPT360014B (or 15C) chassis, what is the correct way to adjust the signal because I noticed that the new radios limit the reception in the adjustments of the coils, that is, if I adjust the coils I get greater sensitivity and consequently a higher sinad ratio but it is factory set to something around 10 or 12DB depending on the manufacturer. So my doubt is what is the correct way to make this limitation in 12DB, which coils do I have to attenuate to reach this value?

[eswnl]

Other sources say that SINAD is ratio of powers, not voltage.

[dennisqwertyuiop]

i have same hp generator as you..the var knob, does it run like a control or is it encorder type, , , always wondering, , my other hp has decoder typy
