Airport Shuttle Bus | Wuzhoulong FDG6139 | ATB1959

Airport Shuttle Bus

🚍General Information of Wuzhoulong Airport Shuttle Bus Model FDG6139

WZL TRANSPORT BUS is a low-floored airport bus & can accommodate up to 110 passengers.
Top speed: 60 km/h
Al Shatei ATB is equipped with the unique pneumatic lifting and lowering system. Before embarking or disembarking of passengers, the bus can be lowered and lifted up again for driving. When the bus opens its doors, it automatically lowered itself for the convenient boarding/alighting of passengers. And when it closes, the bus will return back to its original position.

🚍Accommodation
- Seated Passengers 10
- Standing Passengers 100 approx.

🚍Engine
4 cylinders in-line diesel engine type BF4M1013-19 (Euro 3) with displacement of 4,760 cm3.
Engine Rated power of 140KW at 2,300 rpm.
Max Torque: 700n.m/1400r/min.
Two engines (front & rear) should be equipped with highly sound insulation.

🚍Transmission: American Alison T270R, automatic transmission

🚍Suspension
Front: Two units airbags & two units shock absorbers.
Rear: Four units airbags & four units shock absorbers.

🚍Brakes (Front and Rear) and Air Supply
Full air brakes are on all four wheels according to ECE standard..
With two-circuit system and four-way protection valve.
One (1) air compressor w/ operating pressure of 10 bars.
Parking brake cylinder acting on two wheels with emergency parking brake release system.

🚍Fuel Tank
250 liters capacity (approx)

🚍Two-Way Exhaust System
While the doors are open the exhaust fumes are directed to the side at which doors are closed.
The direction of the exhaust fumes is done automatically by simply pressing the door open button.

🚍Cooling System
Water-cooled engine with cooler

🚍 Electrical System
Battery 200Ah×2, engine driven alternators 140A 28V

🚍 Instruments
Equipped CAN system, speedometer , instrument set containing for each brake-circuit air pressure gauge.
Oil pressure gauge (integrated in display).
Cooling water temperature gauge, fuel level gauge, engine hour meter (integrated in display), various indicators and warning lights.
