Superfine mill machine,Powder grinding equipment operated

After crushed by hammer crusher, the large materials become small ones and are sent to storage hopper by elevator, and then evenly sent to the upper distribution plate of the turn plate by vibrating feeder and sloping feeding pipe.
When the ultrafine grinding mill is at work, the main bearing and each dial are driven by electromotor through reducer, and all the grinding rollers are rolling in the ring channels driving by dial through plunger. The materials are driven to the edge of the turn plate by the centrifugal force and fall down into the grinding chambers.
The high-pressure air blower constantly inhales air, the airflow with crushed materials are brought to the classifier whose high-speed impeller will screen the airflow: the unqualified particle size will fall and return to the mill for being reground while the qualified particle size mixed with air will go into the cyclone powder collector. Most of the qualified powders will fall and exit from the discharging valve at the bottom; a small proportion of the fine powders, with airflow, moves to the dust cleaner. The materials from the above two lots are sent by the conveyor to get finished powders packed. In addition, filtered clean air will be emitted from muffler in the end.
Main Specification of mill machine:
Model HGM80 HGM90 HGM100L HGM125 HGM1680
Ring Diameter(mm) 800 900 1000 1250 1680
Ring Number(layer) 3 3 4 4 4
Roller Number(piece) 18-21 24-29 28-36 30-40 30-44
Main Shaft Speed (r.p.m) 230-240 200-220 180-200 135-155 120-130
Input Size(mm) ≤20 ≤20 ≤20 ≤20 ≤20
Finished Size(um/mesh) 5-74
(325-2500) 5-74
(325-2500) 5-74
(325-2500) 6-100
(325-2500) 9-100
(325-2500)
Capacity(t/h) 0.5-4.5 0.6-6.5 1-9 2.8-20 5-45
Overall Dimension(L*W*H,m) 13.9*4*6.2 14.7*4.8*7.2 18*4.6*8.6 14*9*10.25 26.3*7.5*11.9
Note: The capacity is based on the domestic CaCO3 powder factory's feedback.

Powder Parameter

Unit:KW HGM80 HGM90 HGM100L HGM125 HGM1680
Main unit 55-75 2*45 132-150 185-200 315
Classifier 18.5 18.5 30 37-4*15 5*18.5
Blower 45 55 75 110 2*75-2*90
Crusher 18.5 18.5 18.5 45 45
Bucket Elevator 3 3 4 4 7.5
Feeder 1.5 1.5 1.5 1.5 2.2
Discharging Valve 2*0.75 1*0.75-1*1.1 2*1.1 2*1.1 2*0.75-2*1.5
Air Compressor 11 15 22 37 55
